VPDBVE32E (D1) Proportional pressure valve HOERBIGER HAWE, 20-350 bar, 24 VDC, 320 l/min

HV03580
Qje12-320 l/min
Pje 20-350 bar
Ije50-680mA
Uje 1.8-24 V DC
VPDBVE32E (D1) / HV03580
24,641 Kč bez DPH
29,816 Kč Tax included

29,816 Kč ks

Quantity
Last items in stock 6-7 týdnů

Compare
Proportional valves VPDB VE 32 E from the German manufacturer HOERBIGER are intended for hydraulic systems where the highest requirements are imposed. Enables smooth and precise pressure adjustment. It is easily adjustable with a control signal, a potentiometer, or via a relay. This servo valve is most often found in TRUMPF press brakes.
The package also includes a CVSE32C08 logic valve cartridge.
VPDB VE 32 E (D1) / HV03580
HV03580
1 Item

Data sheet

Mass
2.2 kg
Designation
VPDBVE32E (D1) / HV03580
Maximum pressure
350.0 bar
Control signal
1.8-24V DC / 50-680mA
Flow regulation
It doesn't have
Pressure regulation
20-350 bar
Maximum flow
320.0 l/min
Minimum flow
12.0 l/min
Abbreviated name
VPDBVE32E (D1) / HV03580
New
